Hastelloy C276
Ken-tron draws Hastelloy C276, Hastelloy C22, Hastelloy G30, Hastelloy B3, Hastelloy X, Hastelloy C4, Hastelloy C2000, Hastelloy G35, Hastelloy N and Ultimet and other corrosion-resistant alloys for our drawn wire customers. Ken-tron customers use corrosion-resistant metal wire alloys to produce items for the aerospace, weaving, spring, and other industries.
Hastelloy C276® is a Nickel-Molybdenum-Chromium and Tungsten corrosion resistant alloy.
Hastelloy C276® is used for springs and weaving wire.
Chemical Composition
| ASTM B-574 UNS N10276 |
|
|---|---|
| Iron | 4.0 – 7.0 |
| Copper | – |
| Molybdenum | 15.0 – 17.0 |
| Nickel | Remainder |
| Manganese | 1.0 Max |
| Silicon | .08 Max |
| Carbon | .010 Max |
| Aluminum | 0.00 |
| Cobalt | 2.5 Max |
| Chromium | 14.5 – 16.5 |
| Sulfur | .03 Max |
| Phosphorus | .04 Max |
| Tungsten | 3.0 – 4.5 |
| Vanadium | .35 Max |
| Titanium | – |
| Tantalum | – |
| Nitrogen | – |
| AMS B-574 UNS 10276 | |
|---|---|
| Temper | PSI Range |
| Spring | 212,000 – 268,000 |
| Soft | 145,000 Maximum |
Other Properties
| Density (lbs/in3) | .321 |
| Melting Point (°F) | 2498 |
The Ken-tron Wire Division specializes in small diameter close tolerance wire made to customer specifications. Ken-Tron manufactures to your custom specifications.
